| Product Name |
MasterBox MB510L |
| Model number |
MCB-B510L-KANN-S00(Red)
MCB-B510L-KANN-S01(Black)
MCB-B510L-KANN-S02(White)
MCB-B510L-KANN-S03(Blue) |
| Available Color(s)* |
Red, Black, White, Blue |
| Materials |
Steel, Plastic |
| Dimensions (L x W x H) |
496 x 217 x 468 mm |
| Motherboard Support |
ATX ( up to 272mm width), Micro-ATX, Mini-ITX |
| Expansion Slots |
7 |
| 5.25" Drive Bays |
No |
| Combo 3.5"/2.5" Drive Bays |
2 (Max. 2) |
| SSD Drive Bays |
4 (Max. 6) |
| I/O Panel |
USB 3.0 x 2, Audio In / Out |
| Pre-installed Fan(s) |
Rear: 120mm x 1 |
| Fan Support |
Top: 120mm x 2 / 140mm x 2
Front: 120mm x 3 / 140mm x 2
Rear: 120mm x 1
|
| Liquid Cooling Support |
Front: 120 / 140 / 240 / 280 / 360mm (75mm clearance)
Top: 120 / 240mm
Rear: 120mm
|
| Clearances |
CPU Cooler: 165mm / 6.49"
PSU: 180mm / 7.08"
GFX: 410mm / 16.10"
|
| Cable Routing |
Behind MB Tray: 19mm / 0.74" |
| Dust Filters |
Front, Bottom |
| Power Supply Support |
Bottom mount, ATX |
| Carton Dimension (L x W x H) |
52.3 x 27.6 x 56.8 cm |
| EAN Code |
4719512072196 (MCB-B510L-KANN-S00, Red)
4719512072189 (MCB-B510L-KANN-S01, Black)
4719512072202 (MCB-B510L-KANN-S02, White)
4719512072219 (MCB-B510L-KANN-S03, Blue) |
| UPC Code |
884102044694 (MCB-B510L-KANN-S00, Red)
884102044687 (MCB-B510L-KANN-S01, Black)
884102044700 (MCB-B510L-KANN-S02, White)
884102044717 (MCB-B510L-KANN-S03, Blue) |
| Note |
* Availability may vary depending on region |
