| Product Name |
MasterCase Pro 6 |
| Model Number |
Blue LED version: MCY-C6P2-KW5N
Red LED version: MCY-C6P2-KW5N-01 |
| Available Color |
Dark metallic grey exterior with black interior |
| Materials |
Steel body, Plastic panels |
| Dimensions (LxWxH) |
544 x 235 x 548mm |
| Net Weight |
11.74 Kg |
| Motherboard Support |
ATX, Micro-ATX, Mini-ITX |
| Expansion Slots |
7 |
| Drive Bays |
5.25" |
2 |
| Combo 3.5" / 2.5" |
5 |
| SSD |
2 |
| Electronics |
I/O Panel |
USB 3.0 x 2
Audio in / out |
| Pre-installed Fan(s) |
Front |
140mm x 2 |
| Rear |
140mm Blue / Red LED Fan x 1 |
| Fan Support |
Front |
120mm x 3 / 140mm x 3 |
| Rear |
120mm x 1 / 140mm x 1 |
| Top |
120mm x 2 / 140mm x 2 |
| Liquid Cooling Support |
Front |
240 / 280mm |
| Rear |
120 / 140mm |
| Top |
240mm (max. 297mm radiator length) |
| Clearance |
CPU Cooler |
190mm / 7.48" |
| PSU |
200mm / 7.87" |
| Graphics Card |
412mm / 16.22" (without 3.5" HDD cage)
296mm / 11.7" (with 3.5" HDD cage) |
| Cable Routing |
Behind Motherboard Tray |
25mm - 35mm |
| Dust Filters |
Front, bottom |
| Power Supply |
Bottom mount, ATX |
| Extra features |
Side Window Panel
Front bottom Blue or Red LED Strip x 1 |
| EAN Code |
Blue LED version: 4719512054086
Red LED version: 4719512057452 |
| UPC Code |
Blue LED version: 884102030185
Red LED version: 884102031083 |
