| Model Number |
MCX-0005-KKN00 (not windowed)
MCX-0005-KWN00 (windowed)
|
| Available Color |
Dark metallic grey exterior with black interior |
| Materials |
SECC, Plastic |
| Weight |
10.6 kg / 23.4 lb |
| Dimensions |
All |
512(L) x 235(W) x 548(H) mm |
| Body |
460(L) x 235(W) x 460(H) mm |
| M/B Type |
ATX, microATX, Mini-ITX |
| Expansion Slots |
7 |
| Drive Bay |
5.25" ODD |
2 |
| 3.5" HDD |
2 |
| 2.5" SSD |
2 + 2 |
| I/O Panel |
USB 3.0 x 2, Audio In & Out (supports HD-Audio) |
| Cooling Support |
Front |
140mm x1 (pre-Installed)
120/140mm x2 (optional) |
| Rear |
140mm x1 (pre-Installed) |
| Top |
120/140mm x2 (optional) |
| Radiator Support |
Front |
240mm/280mm (up to 40mm thickness without fan) |
| Rear |
120mm/140mm |
| Top |
N/A |
| CPU Air Cooling Support |
190mm/7.5 inch |
| VGA Card Support |
w/ 3.5" HDD Cage |
296mm/11.7 inch |
| w/o 3.5" HDD Cage |
412mm/16.2 inch |
| Cable Management |
25mm |
| Dust Filters |
Front/Top/Bottom |
| Power Supply Type |
Bottom Mount, ATX PS2 |
| EAN Code |
4719512048283 (MCX-0005-KKN00)
4719512052488 (MCX-0005-KWN00) |
| UPC Code |
884102027246 (MCX-0005-KKN00)
884102028595 (MCX-0005-KWN00) |
